Shallow Well Jet Pump 1/2HP
-
Model Number:
SNC-L
-
Product Name:Shallow Well Jet Pump 1/2HP
-
Manufacturer:
-
Series (35 Models):
1/2HP 115/230v
Model Number
SNC-L
25% Off
Special Price
$879.75
Regular Price
$1,173.00
Sta-Rite SNC-L
1/2HP Shallow Well water jet pump. Quality Construction - Close-grained
cast iron pump body is rugged, one-piece unit, specially treated to
resist corrosion. Drain port provided for easy winterizing. Does
not include nozzle jet for deep well. Option depending on well
depth. Can be used for shallow well, irrigation, wash down,
recycled water filters on commercial waste water systems.
Precision Molded Diffuser - Pump primes faster, handles more air,
with multi-port, precision-molded, reinforced polypropylene
diffuser.
Motor Windings - Superior insulation materials protect against
excessive moisture and contaminantsâ‘·ssures
prolonged motor life.
Heavy-duty Ball Bearings - Shielded, permanently lubricated
bearings, extensively tested to ensure extended life and smooth
quiet operation.
FEATURES
- Dual-voltage, 115/230-volt
- Rugged one-piece,close-grain cast iron pump body
- Quality Construction - Close-grained cast iron body. Drain port provided for easy winterizing
- Suction lift up to 25FT
- Cast iron shallow-well and deep well jet packs - sold separately
- Precision Molded Diffuser - Pump primes faster, handles more air, with multi-port, precision-molded, reinforced polypropylene diffuser.
- Powered by A. O. Smith, 2-compartment, square flange motor, thermal overload protected. Heavy-duty Ball Bearings - Shielded, permanently lubricated bearings, extensively tested to ensure extended life and smooth quiet operation. Motor Windings - Superior insulation materials protect against excessive moisture and contaminants and assure prolonged motor life.
- UL, CSA Listed
| Model Number | SNC-L |
|---|---|
| Series | Sta-rite Jet Pumps Convertible |
| Max Flow (GPM.) | 9 |
| Max Flow GPH | 540 |
| TDH Maximum (Ft) | 160 |
| TDH Maximum (PSI) | 70 |
| Horsepower (IE .5, 1, 1.5, 20) | .05 |
| Inlet Connection Type | FNPT |
| Inlet (In.) | 1.25 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1 |
| Wetted Materials | CI-Plastic |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 115/230 |
| Voltage (Range) | 110-120/220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor | ODP |
| Motor Frame | 48 |
| Self Priming | Yes |
| Suction Lift (FT.) | 25 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Shaft | 416SS |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Motor Bearings | Ball |
| Other | 30-50 switch setting |
| Approvals | cUL |
| Impeller Material | Noryl, closed |
| Cord Length (Ft.) | 0 |
| Duty | See performance chart |
| Drain | Yes |
| Port Rotation | No |
| Weight (Lbs) | 45.000000 |
| Warranty (YRS.) | 1 |
| GPM Of Water At 100 Feet Of Head | 6 |
>
