Sump pump Pro grade Cast Iron
-
Model Number:
S5033
-
Product Name:Sump pump Pro grade Cast Iron
-
Manufacturer:
-
Series (35 Models):
1/3HP NO SWITCH
Model Number
S5033
$352.50
Pro Series S5033
Industrial grade submersible pumps for the residential
market.
Pro Series submersible pumps. Sump pump, submersible dewatering pump, fountain pump.NO FLOAT SWITCH. Can be ordered seperatly Not all sump pumps are created equal!
They're strong and dependable. Dim. 13.78"H x 8.86"D Features
- Continuous duty construction
- Cast iron housing
- Capacitor start
- Stainless steel shaft
- Upper and lower ball bearings
- Dual carbon ceramic seals with additional third shaft seal
- Dynamically balanced cast iron impeller
- Stainless steel fasteners
- Stainless steel removable strainer
- 20' cord length
- Optional Dual Float Controller or other solid state level controls
- Energy efficient
| Model Number | S5033 |
|---|---|
| Series | Pro Series submersible pumps |
| Max Flow (GPM.) | 56 |
| Max Flow GPH | 3360 |
| TDH Maximum (Ft) | 26 |
| TDH Maximum (PSI) | 11 |
| Horse Power (HP) | 1/3 |
| Horsepower (IE .5, 1, 1.5, 20) | 0.3300 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1.5 |
| Wetted Materials | 416SS, Cast Iron |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 115 |
| Voltage (Range) | 110-120 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor Amps (A) | 4 |
| Motor | Hermetically Sealed |
| Speed (RPM.) | 3450 |
| Max Operating Temperature (F) | 104 |
| Viscosity | Milk 3.20 cp 40.00 ssu |
| Shaft | 416SS |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Double |
| Motor Bearings | Ball |
| Other | The Dual Float switch:
|
| Cord Length (Ft.) | 20 |
| Duty | Continuous |
| Weight (Lbs) | 35.000000 |
| Warranty (YRS.) | 4 |
| GPM Of Water At 10 Feet Of Head | 59 |
>
