SS Pump 15 HP ODP
-
Model Number:
A3U-40-200B-150D3G
-
Product Name:SS Pump 15 HP ODP
-
Manufacturer:
-
Series (24 Models):
15HP 230/460V ODP
Model Number
A3U-40-200B-150D3G
$4,198.00
EBARA A3U-40-200B-150D3G
The EBARA A3U-40-200B-150D3G is a 15 HP stainless steel end-suction centrifugal pump from EBARA's 3U series, engineered for dependable, continuous-duty performance under demanding commercial and industrial conditions. All-stainless-steel construction resists corrosion in process water, food & beverage, and general industrial transfer duty. Configured with a 230/460V ODP motor. Part of the 3U family, which spans 1/2 HP to 25 HP with flows to 380 GPM and heads to 255 ft.
Features are:
- 304 Stainless steel case, motor bracket close coupled centerline
- Flanged discharge
- Back pullout
- High operating efficiencies.
These pumps are available in either ODP & TEFC MOTORS and single phase or three phase Optional FKM seals also.
NSF-certified models with “C” suffix are available if requested.
| Model Number | A3U-40-200B-150D3G |
|---|---|
| Series | 3U SS End Suction Centrifugal 380GPM or 255FT |
| Max Flow (GPM.) | 250 |
| Max Flow GPH | 15000 |
| TDH Maximum (Ft) | 277 |
| TDH Maximum (PSI) | 120 |
| Horse Power (HP) | 15 |
| Horsepower (IE .5, 1, 1.5, 20) | 15.0000 |
| Inlet Connection Type | Flange |
| inlet size | 2 ½" |
| Inlet (In.) | 2.5 |
| Outlet Connection Type | Flange |
| Outlet (In.) | 1.5 |
| Wetted Materials | 304SS |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 230/460 |
| Voltage (Range) | 220-240/460-480 |
| Phase (Ø) | Three (3) |
| Motor Frequency | 60 |
| Motor | ODP |
| Speed (RPM.) | 3450 |
| Motor Frame | 213/5JM |
| Self Priming | No |
| Max Operating Temperature (F) | 212 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Shaft | 416SS |
| Length (In.) | 21.800000 |
| Mechanical Seal | TYPE 21 |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Impeller Size (IN.) | 8.870000 |
| Coupling | N |
| Other | max. working 230 PSI. |
| Rotation | CW facing motor side of pump |
| Impeller Material | SS, Closed |
| Cord Length (Ft.) | 0 |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | No |
| Weight (Lbs) | 182.000000 |
| Warranty (YRS.) | 1 |
| GPM Of Water At 250 Feet Of Head | 160 |
