FM5 Bronze pump 2HP
-
Model Number:
26603
-
Product Name:FM5 Bronze pump 2HP
-
Manufacturer:
-
Series (17 Models):
2HP 115/230v
Model Number
26603
25% Off
Special Price
$2,622.00
Regular Price
$3,496.00
MP 26603
Flomax Marine Bronze pump 2HP by MP
FM5 bronze are self-priming pumps, pipe size 1.5" NPT. Bilge / Saltwater Pump. Pump with standard 115/230v TEFC motor.
The MP Pumps Flomax 5 Bronze Self-Priming Centrifugal Pump is a heavy-duty industrial and marine pump designed for high-capacity liquid transfer, bilge service, agricultural spraying, and corrosive or ballast duties.
Specifications
- Port Size: 1-1/2" x 1-1/2" NPT (suction and discharge)
- Maximum Flow Rate: Up to 145 GPM (gallons per minute)
- Maximum Head Pressure: Up to 100 feet (approx. 40 PSI)
- Suction Lift: Self-priming up to 25 feet with a built-in flapper check valve
- Impeller Size: 5.0-inch semi-open dynamically balanced impeller
- Construction Material: Bronze housing, bronze/corrosion-resistant internals, stainless steel fasteners, and a Viton mechanical seal
- Electric motor is TEFC
Motor base shown is a Option, order separately.
| Model Number | 26603 |
|---|---|
| part number | MP26603 |
| Series | Flomax 5 Pump |
| Max Flow (GPM.) | 100 |
| Max Flow GPH | 6000 |
| TDH Maximum (Ft) | 58 |
| TDH Maximum (PSI) | 25 |
| Horse Power (HP) | 2 |
| Horsepower (IE .5, 1, 1.5, 20) | 2.0000 |
| Inlet Connection Type | FNPT |
| inlet size | 1 ½" |
| Inlet (In.) | 1.5 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1.5 |
| Wetted Materials | Bronze |
| Elastomers / O-ring | FKM |
| Voltage (V) | 115/230 |
| Voltage (Range) | 110-120/220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor | TEFC |
| Speed (RPM.) | 3450 |
| Motor Frame | 56C |
| Self Priming | Yes |
| Suction Lift (FT.) | 25 |
| Max Operating Temperature (F) | 120 |
| Viscosity | Cream 16.50 cp 100.00 ssu |
| Shaft | 416SS |
| Mechanical Seal | FKM |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Motor Bearings | Ball |
| Impeller Size (IN.) | 4.620000 |
| Coupling | Y |
| Impeller Material | Bronze, semi-open |
| Cord Length (Ft.) | 0 |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | Yes |
| Country of Manufacture | United States |
| Weight (Lbs) | 65.000000 |
| Warranty (YRS.) | 1 |
