Pressure Hand Pump
-
Model Number:
WP2
-
Product Name:Pressure Hand Pump
-
Manufacturer:
-
Series (2 Models):
Model Number
WP2
$128.00
PumpBiz WP2
Reliable Hand Pump for Wells, Springs, Cisterns, and Remote Water Access
The PumpBiz WP2 (Oasis Pump) is a lightweight, durable hand-lift pump designed for wells, cisterns, springs, buried tanks, rivers, and streams where the maximum lift is 28 to 30 feet (9 meters) ideal for remote or off-grid locations. It’s also commonly used as a pump primer for other pumping systems.
This WP2 model is a pressure version of the standard W1, offering the ability to discharge water under pressure, making it compatible with piping systems or hose connections.
Key Features:
- Discharge pressure up to 0–20 PSI during normal operation (up to 50 feet of head).
- Discharge outlet fits standard 1.5inch pipe socket fittings — plumb to plastic piping (epoxy or silicone weld) or adapt to hoses.
- Suction inlet: 2 inch FNPT (female NPT threaded connection).
- Saltwater and chemical-resistant materials for broad durability.
- Compact and lightweight – easy to transport and install.
Ideal Applications:
- Campsites
- Summer homes and cottages
- Stock watering
- Rural dwellings
- Parks and picnic areas
- Plant nurseries
- Remote villages
- Well sampling and de-watering
| Model Number | WP2 |
|---|---|
| Series | Oasis Hand Water Pump |
| Max Flow (GPM.) | 10 |
| Max Flow GPH | 600 |
| TDH Maximum (Ft) | 50 |
| TDH Maximum (PSI) | 22 |
| Inlet Connection Type | FNPT |
| inlet size | 2in |
| Inlet (In.) | 2 |
| Outlet (In.) | 1.5 |
| Wetted Materials | PolyPro |
| Elastomers / O-ring | Buna-Nitrile |
| Diaphragm | Urethane |
| Self Priming | Yes |
| Suction Lift (FT.) | 28 |
| Max Operating Temperature (F) | 120 |
| Shaft | 304SS |
| Length (In.) | 18.000000 |
| Mechanical Seal | No |
| Mechanical Seal Type | Double |
| Other | For smaller size suction connection, use a 2" x _ adapter bushing. Sold seperately. |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 3.000000 |
| Warranty (YRS.) | 1 |
