Duplex Alternator Pump Control Panel
-
Model Number:
1221W110H
-
Product Name:Duplex Alternator Pump Control Panel
-
Manufacturer:
-
Series (28 Models):
115/208/230v 7-15A
Model Number
1221W110H
$1,334.30
Rhombus 1221W110H
Duplex pump alternator alarm system and pump control
for single phase pumps. Used for sump and effluent pumps or any other two pumps.
- Includes duplex pump control alternator
- Magnetic motor contactors
- 2 terminal blocks
- 3 floats (1 each for high-water, pump on and pump off)
- Does not include pump disconnects / circuit breakers
- Floats have 20FT power cords
- HOA switch offers either hand, off or automatic operations
- Pump run indicator lights.
- UL listed system
- Starting Device: Magnetic Motor Contactor 120/208/240V only
- Alarm Package: includes test/normal/silence switch, fuse, red light & horn
- Enclosure Rating: Weatherproof, NEMA 4X (thermoplastic)
- Pump Disconnects: No Circuit Breaker
| Model Number | 1221W110H |
|---|---|
| Series | 122 Duplex Pump Systems Control Panel Single Phase |
| Wetted Materials | FRP |
| Voltage (V) | 115/208-230 |
| Voltage (Range) | 110-120/220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor Amps (A) | 7-15 |
| Other | 120/208/240V |
| Approvals | UL |
| Country of Manufacture | United States |
| Weight (Lbs) | 22.000000 |
| Warranty (YRS.) | 3 |
