Combo Sump Pump System

1/3HP sump and the PHCC2400 backup
Model Number
PS-C33
20% Off Special Price $1,010.00 Regular Price $1,261.29
Pro Series PS-C33 Combo Sump Pump System

Pro Series PS-C33

Combo Sump Pump System PSC33. Sump pump AND battery backup sump pump

PHCC2400, dual pump package. The PHCC Pro Series S3 line of sump pumps are powerful, energy efficient, durable water sump pumps capable of high pumping capacities. They include the dual float switch controller DFC1 and are backed by a 3-year warranty. ps-c33

Features

  • Continuous duty construction
  • Cast iron and cast aluminum housing
  • Capacitor start
  • Stainless steel shaft
  • Upper and lower ball bearings
  • Dual carbon ceramic seals
  • Dynamically balanced cast iron impeller
  • Stainless steel fasteners
  • Removable strainer
  • 10' cord length
  • Energy efficient
  • Continuous duty rated
  • Dual float switches on primary and backup pumps
  • Automatically switches to battery power when AC fails
  • Backup pump will assist primary pump if excessive amounts of water are entering the sump
  • Detects irregularities, sounds an alarm, and pinpoints problems and solutions on control panel
  • Maintains and recharges battery automatically
  • Alarm can be silenced during a power outage
  • Output terminals for connection to a security system or auto-dialer (PS-C33 only)
  • Can accommodate two (2) B2200 batteries for 16 hours of continuous pumping (PS-C33 only)
  • 3-year warranty
  • Water cooled (no oil to leak)

Backup Pump Monitoring with alarm for:

  • Battery needs water
  • Battery is old and needs to be replaced
  • Battery is discharged or defective
  • Cable is loose or terminals are corroded
  • Power, fuse or circuit breaker has failed
  • Pump has been activated; check the main pump for failure
  • Backup pump defective or clogged

Added Features:

  • Automatically tests pump weekly
  • Backup pump runs off AC power as well as battery power
  • Displays percentage of power remaining in the battery

High flow 3000 GPH @ 10' (50 GPM @10') main AC powered pump Popular 2400 GPH battery backup pump with feature rich controller, automatic battery charger. Order battery accessory separately.

More Information
Model Number PS-C33
Series Pro Series submersible pumps
Max Flow (GPM.) 53
Max Flow GPH 3180
TDH Maximum (Ft) 26
TDH Maximum (PSI) 11
TDH BEP (FT.) 10.000000
Horse Power (HP) 1/3
Horsepower (IE .5, 1, 1.5, 20) 0.3300
Outlet Connection Type FNPT
Outlet (In.) 1.5
Wetted Materials 304SS, CI-Plastic
Elastomers / O-ring Buna-Nitrile
Voltage (V) 115
Voltage (Range) 110-120
Phase (Ø) Single (1)
Motor Frequency 60
Motor Hermetically Sealed
Self Priming Yes
Max Operating Temperature (F) 104
Viscosity Water 1.00 cp 31.00 ssu
Length (In.) 25.000000
Mechanical Seal No
Mechanical Seal Face Carbon-ceramic
Mechanical Seal Type Single
Drain Yes
Port Rotation Yes
Weight (Lbs) 38.000000
Warranty (YRS.) 3 - 4
