Bronze Pedestal Pump 1HP
-
Model Number:
3704-97
-
Product Name:Bronze Pedestal Pump 1HP
-
Manufacturer:
-
Series (14 Models):
AMT 3704-97
AMT Bronze Pedestal PTO pumps are designed for continuous-duty OEM, Industrial/Commercial and processing applications including circulation, chemical processing, liquid transfer, heating and cooling. The high head models are ideal for sprinkler systems and pressure boosting. See performance curve under IMAGE tab for speed vs flow relationship.
These units are available in a variety of construction and seal materials. Pull-from-the-rear design permits easy servicing without disturbing any piping. Pedestals feature CNC machined shafts with sealed ball bearings. Models 4897 and 4906 pedestal drive are epoxy coated and include 304 stainless steel shafts. See Curve "D" General Service Model not High Head Model
Click here to view the accessories (wheel kits, hoses, strainers..) for AMT products
For other style / sizes of PTO Pedestal pumps.
| Model Number | 3704-97 |
|---|---|
| part number | 3704-999-97 |
| Series | Centrifugal Pedestal Pumps |
| Max Flow (GPM.) | 58 |
| Max Flow GPH | 3480 |
| TDH Maximum (Ft) | 58 |
| TDH Maximum (PSI) | 25 |
| inlet size | 1in |
| Inlet (In.) | 1 |
| Outlet (In.) | 1 |
| Wetted Materials | Bronze |
| Elastomers / O-ring | Buna-Nitrile |
| Motor Amps (A) | 2 |
| Motor | ODP |
| Self Priming | ---- |
| Suction Lift (FT.) | 5 |
| Max Operating Temperature (F) | 120 |
| Max Particle Size (In) | .2 |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Impeller Size (IN.) | b |
| Impeller Number (In.) | 3 |
| Other | amt pump |
| Rotation | cw |
| Drain | No |
| Country of Manufacture | United States |
| Weight (Lbs) | 50.000000 |
| UPC | 072684650097 |
| Warranty (YRS.) | 1 |
Supporting Docs
AMT Pump Company is A Subsidiary of The Gorman-Rupp Company located in Mansfield, Ohio. AMT offers over 1000+ different standard model numbers of which 400+ are readily available and offered as QSP, Quick Ship Products. AMT manufactures and sells Industrial / Commercial pumps & accessories through authorized distributors.
Virtually every product AMT sells is engineered and designed by the company. Pump components are machined, assembled and tested at the Royersford, Pennsylvania facility.
AMT’s unique designs and patented products have made the company the industry leader for their high quality pumps.
