Bronze Centrifugal Pedestal Pump .5HP
-
Model Number:
3682-97
-
Product Name:Bronze Centrifugal Pedestal Pump .5HP
-
Manufacturer:
-
Series (14 Models):
AMT 3682-97
These units are available in a variety of construction and seal materials. Pull-from-the-rear design permits easy servicing without disturbing any piping. Pedestals feature CNC machined shafts with sealed ball bearings. Casing is Bronze. Impeller is SS See Curve "E" General Service Model not High Head Model
| Model Number | 3682-97 |
|---|---|
| part number | 3682-999-97 |
| Series | Centrifugal Pedestal Pumps |
| Max Flow (GPM.) | 35 |
| Max Flow GPH | 2100 |
| TDH Maximum (Ft) | 57 |
| TDH Maximum (PSI) | 25 |
| inlet size | Less than 1in |
| Inlet (In.) | 0.75 |
| Outlet (In.) | 1 |
| Wetted Materials | 416SS, Bronze |
| Elastomers / O-ring | Buna-Nitrile |
| Motor Amps (A) | 2 |
| Motor | ODP |
| Self Priming | ---- |
| Suction Lift (FT.) | 5 |
| Max Operating Temperature (F) | 120 |
| Max Particle Size (In) | .2 |
| Viscosity | Milk 3.20 cp 40.00 ssu |
| Shaft | 416SS |
| Mechanical Seal | FKM |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Impeller Size (IN.) | b |
| Impeller Number (In.) | 3 |
| Other | amt pump |
| Rotation | cw |
| Drain | No |
| Country of Manufacture | United States |
| Weight (Lbs) | 10.000000 |
| UPC | 072684650096 |
| Warranty (YRS.) | 1 |
Supporting Docs
AMT Pump Company is A Subsidiary of The Gorman-Rupp Company located in Mansfield, Ohio. AMT offers over 1000+ different standard model numbers of which 400+ are readily available and offered as QSP, Quick Ship Products. AMT manufactures and sells Industrial / Commercial pumps & accessories through authorized distributors.
Virtually every product AMT sells is engineered and designed by the company. Pump components are machined, assembled and tested at the Royersford, Pennsylvania facility.
AMT’s unique designs and patented products have made the company the industry leader for their high quality pumps.
