7 GPM Submersible 3/4HP
-
Model Number:
S7P4HS07221
-
Product Name:7 GPM Submersible 3/4HP
-
Manufacturer:
-
Series (6 Models):
Model Number
S7P4HS07221
25% Off
Special Price
$2,595.86
Regular Price
$3,461.15
Sta-Rite S7P4HS07221
Sta-rite Submersible Water Well Pumps. Sta-rite Submersible water
well pumps are precision-engineered, stainless steel Signature
2000® pumps that deliver efficient, dependable
performance even in rough, aggressive water. Floating impeller
design resists sand and reduces sand locking.
- Applications: water systems for residential, industrial, commercial, multiple housing and farm use.
- Patented Staging System: The SignaSeal™ staging system has a harder-than-sand ceramic wear surface that when incorporated with the floating impeller design, greatly reduces problems with abrasives, sand lock-up and running dry.
- Discharge/Intake: Corrosion-resistant 300 grade stainless steel for durability in aggressive water.
- Discharge Bearing: Exclusive self-lubricating Nylatron® bearing resists wear from sand.
- Shaft: Positive drive from 7/16" hexagonal heavy-duty 300 grade stainless steel.
- Coupling: SS press fit to pump shaft. Couples to all standard NEMA motors.
- Shell: Heavy-walled corrosion-resistant stainless steel. Threaded for easy servicing.
- Hardware: All screws, washers and nuts and corrosion-resistant 300 grade stainless steel.
- Check Valve: Durable internal spring-loaded check valve. (not included on 5HP, 7-1/2HP, and 10HP models and 50 GPM models)
- Cable Guard: Corrosion-resistant stainless steel guard protects motor leads. Tapered ends prevent pump from catching on well.
- Intake Screen: Corrosion-proof polypropylene.
- Franklin Electric Motor: NEMA standard super stainless series water filled motors.
- UL and CSA listed.
- This pump has a 2-wire motor (3-wire motors are available upon request by calling 1-800-PUMPBIZ)
| Model Number | S7P4HS07221 |
|---|---|
| Series | H & HL series Signature 2000 SS Submersible Well Pumps |
| Max Flow (GPM.) | 10 |
| Max Flow GPH | 600 |
| TDH Maximum (Ft) | 400 |
| TDH Maximum (PSI) | 173 |
| Horse Power (HP) | 3/4 |
| Horsepower (IE .5, 1, 1.5, 20) | 0.7500 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1.25 |
| Wetted Materials | SS-Plastic |
| Voltage (V) | 230 |
| Voltage (Range) | 220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor | Hermetically Sealed |
| Self Priming | Yes |
| Stages | 13 |
| Shaft | 304SS |
| Mechanical Seal | No |
| Mechanical Seal Type | Double |
| Other | 2 WIRE MOTOR |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 34.000000 |
| Warranty (YRS.) | 1 |
