50 GPM Submersible 1-1/2HP PEO
-
Model Number:
L50P4FH
-
Product Name:50 GPM Submersible 1-1/2HP PEO
-
Manufacturer:
-
Series (6 Models):
Model Number
L50P4FH
Sta-Rite L50P4FH
Pump End Only Sta-rite Submersible Water Well Pumps.
Sta-rite Submersible water well pumps are precision-engineered,
stainless steel Signature 2000® pumps that deliver
efficient, dependable performance even in rough, aggressive water.
Floating impeller design resists sand and reduces sand locking.
- Applications: water systems for residential, industrial, commercial, multiple housing and farm use.
- Patented Staging System: The SignaSeal™ staging system has a harder-than-sand ceramic wear surface that when incorporated with the floating impeller design, greatly reduces problems with abrasives, sand lock-up and running dry.
- Discharge/Intake: Corrosion-resistant 300 grade stainless steel for durability in aggressive water.
- Discharge Bearing: Exclusive self-lubricating Nylatron® bearing resists wear from sand.
- Shaft: Positive drive from 7/16" hexagonal heavy-duty 300 grade stainless steel.
- Coupling: SS press fit to pump shaft. Couples to all standard NEMA motors.
- Shell: Heavy-walled corrosion-resistant stainless steel. Threaded for easy servicing.
- Hardware: All screws, washers and nuts and corrosion-resistant 300 grade stainless steel.
- Check Valve: Durable internal spring-loaded check valve. (not included on 5HP, 7-1/2HP, and 10HP models and 50 GPM models)
- Cable Guard: Corrosion-resistant stainless steel guard protects motor leads. Tapered ends prevent pump from catching on well.
- Intake Screen: Corrosion-proof polypropylene.
- UL and CSA listed.
| Model Number | L50P4FH |
|---|---|
| Series | H & HL series Signature 2000 SS Submersible Well Pumps |
| Max Flow (GPM.) | 80 |
| Max Flow GPH | 4800 |
| TDH Maximum (Ft) | 150 |
| TDH Maximum (PSI) | 65 |
| Horse Power (HP) | 1 1/2 |
| Horsepower (IE .5, 1, 1.5, 20) | 1.5000 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 2 |
| Wetted Materials | SS-Plastic |
| Motor | Hermetically Sealed |
| Speed (RPM.) | 3450 |
| Self Priming | Yes |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Stages | 4 |
| Shaft | 304SS |
| Mechanical Seal | No |
| Mechanical Seal Type | Double |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 12.000000 |
| Warranty (YRS.) | 1 |
