4˝ Self-Priming Semi-Trash Pump 10HP
-
Manufacturer:
-
Series (3 Models):
-
Product Name:4˝ Self-Priming Semi-Trash Pump 10HP
-
Model Number:4871-95
4" 10HP 230/460v
Model Number
4871-95
10% Off
Special Price
$2,754.00
Regular Price
$3,060.00
Self-Priming Semi-trash pump. A robust Cast Iron Centrifugal self priming pump designed for a broad range of high capacity applications, including dewatering, waste pits, liquid transfer, circulation, drainage and irrigation. Dual volute design reduces radial load on motor. The centerline discharge feature is specifically designed to prevent vapor binding and makes for convenient piping connections. All models are fitted with self-cleaning, semi-open stainless steel impeller, which can handle 1/2" diameter semi-solids. Built-in check valves for fast priming are standard on all units. Fill and drain plugs for easy installation and servicing.
Optional Silicon Carbide seal and / or FKM seal and flapper is available. Optional Mounting Base Available on All 4" Models in the 487_ series. A200-90
Hazardous Duty EXplosion Proof 10HP Motors Available;
CALL FOR QUOTATION & LEAD TIME!
| Model Number | 4871-95 |
|---|---|
| part number | 4871-999-95 |
| Series | Cast Iron 4˝ Self-Priming Centrifugal Pump |
| Max Flow (GPM.) | 520 |
| Max Flow GPH | 31200 |
| Minimum Flow (GPM.) | 120 |
| TDH Maximum (Ft) | 105 |
| Horse Power (HP) | 10 |
| Horsepower (IE .5, 1, 1.5, 20) | 10 |
| Inlet Connection Type | FNPT |
| Inlet (In.) | 4 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 4 |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 208-230/460 |
| Voltage (Range) | 208-240/460 |
| Phase (Ø) | Three (3) |
| Motor Frequency | 60 / 50 |
| Motor Amps (A) | 26/13 |
| Motor | TEFC |
| Speed (RPM.) | 3450 |
| Motor Frame | 215JM |
| Self Priming | Yes |
| Suction Lift (FT.) | 20 |
| Max Operating Temperature (F) | 180 |
| Max Particle Size (In) | 0.5 |
| Viscosity | Vegetable Oil 34.60 cp 200.00 ssu |
| Shaft | 304SS |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Impeller Number (In.) | A |
| Other | 1756-004-00 Impeller Screw - 3/8-16X1.25 ALLOY STL PLTD CNTRSNK SCREW. Replace oring also! Use 7/32"allen |
| Impeller Material | 304 SS, semi-open |
| Cord Length (Ft.) | 0 |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | No |
| Country of Manufacture | United States |
| Weight (Lbs) | 290.000000 |
| Quick Ship | Yes |
| UPC | 072684652913 |
| Warranty (YRS.) | 1 |
| GPM Of Water At 40 Feet Of Head | 460 |
| GPM Of Water At 80 Feet Of Head | 250 |
Supporting Docs
Supporting Docs
(Size: 2.46 MB)
Extension: pdf
AMT Pump Company is A Subsidiary of The Gorman-Rupp Company located in Mansfield, Ohio. AMT offers over 1000+ different standard model numbers of which 400+ are readily available and offered as QSP, Quick Ship Products. AMT manufactures and sells Industrial / Commercial pumps & accessories through authorized distributors.
Virtually every product AMT sells is engineered and designed by the company. Pump components are machined, assembled and tested at the Royersford, Pennsylvania facility.
AMT’s unique designs and patented products have made the company the industry leader for their high quality pumps.
