30 GPM Submersible 1HP
-
Manufacturer:
-
Series (8 Models):
-
Product Name:30 GPM Submersible 1HP
-
Model Number:S30P4HS10231-01
1HP 230v/1
Model Number
S30P4HS10231-01
Submersible Water Well Pumps. Submersible water well pumps are
precision-engineered, corrosion-resistant composite Signature
2000® pumps that deliver efficient, dependable
performance even in rough, aggressive water.
- Applications: water systems for residential, industrial, commercial, multiple housing and farm use.
- Patented Staging System: The SignaSeal™ staging system has a harder-than-sand ceramic wear surface that when incorporated with the floating impeller design, greatly reduces problems with abrasives, sand lock-up and running dry.
- Discharge: Corrosion-resistant fiberglass reinforced thermoplastic for durability in aggressive water.
- Discharge Bearing: Exclusive self-lubricating Nylatron® bearing resists wear from sand.
- Intake: Corrosion-resistant fiberglass reinforced thermoplastic for durability in aggressive water.
- Shaft: Positive drive from 7/16" hexagonal heavy-duty 300 grade stainless steel.
- Coupling: SS press fit to pump shaft. Couples to all standard NEMA motors.
- Shell: Heavy-walled corrosion-resistant stainless steel. Threaded for easy servicing.
- Hardware: All screws, washers and nuts and corrosion-resistant 300 grade stainless steel.
- Check Valve: Durable internal poppet type check valve.
- Cable Guard: Corrosion-resistant stainless steel guard protects motor leads. Tapered ends prevent pump from catching on well.
- Intake Screen: Corrosion-proof polypropylene.
- Franklin Electric Motor: NEMA standard super stainless series water filled motors.
- UL and CSA listed.
| Model Number | S30P4HS10231-01 |
|---|---|
| Series | J & JL Signature 2000 Submersible Well Pumps |
| Max Flow (GPM.) | 45 |
| Max Flow GPH | 2700 |
| TDH Maximum (Ft) | 170 |
| TDH Maximum (PSI) | 74 |
| Horse Power (HP) | 1 |
| Horsepower (IE .5, 1, 1.5, 20) | 1.0000 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1.25 |
| Wetted Materials | SS-Plastic |
| Voltage (V) | 230 |
| Voltage (Range) | 220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor | Hermetically Sealed |
| Stages | 5 |
| Shaft | 304SS |
| Length (In.) | 26.500000 |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Other | 3WIRE MOTOR |
| Weight (Lbs) | 37.000000 |
| Warranty (YRS.) | 1 |
