Trash Pump diesel
-
Model Number:
TE2QBB 1B30 K
-
Product Name:Trash Pump diesel
-
Manufacturer:
-
Series (14 Models):
Diesel 2"
Model Number
TE2QBB 1B30 K
$5,175.00
Pacer TE2QBB 1B30 K
Self-priming, light weight Trash pump, diesel engine driven. Industrial Hatz 1B30 diesel engine driven. No spark plug means safer operation. Pump casing is made or rugged glass reinforced polyester, SS fasteners, urethane coated metal impeller and volute resist wear. Stainless Steel Quick Release Band Holds Pump Hosing for easy service in the field. Pressurized oil lubrication system protects hard silicon carbide shaft seal faces and provides lubrication to seal face. Also benefits dry run feature. Includes built in check valve maintains initial prime. May be throttled for control of flow.
Mounted on a rigid steel frame with carry handle and includes only a suction strainer. Centrifugal Pumps.
Pacer Pumps' T Series pumps are self-priming, solids handling centrifugal pumps that will pass a solid half the diameter of the suction port. These pumps are constructed with tough non-metallic corrosion and abrasion resistant materials for general service with water and salt water. Designed for performance, 'T' pumps provide fast, high suction lifts and high flow rates, ideal for de-watering and transferring out of sump, pit, tank, pond, river and aquamarine applications. Pressurized oil lubrication system protects silicon carbide shaft seal faces and the open impeller and double flush volute will help keep the pump free of settled solids.
| Model Number | TE2QBB 1B30 K |
|---|---|
| Series | Trash Pumps Pacer pumps dewatering 360gpm |
| Max Flow (GPM.) | 240 |
| Max Flow GPH | 14400 |
| TDH Maximum (Ft) | 82 |
| TDH Maximum (PSI) | 36 |
| TDH BEP (FT.) | 50.0000 |
| Horse Power (HP) | 7 |
| Horsepower (IE .5, 1, 1.5, 20) | 6.8 |
| Inlet Connection Type | FNPT |
| Inlet (In.) | 2 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 2 |
| Wetted Materials | Polyester |
| Elastomers / O-ring | Buna-Nitrile |
| Motor | Diesel Engine |
| Speed (RPM.) | 3450 |
| Self Priming | Yes |
| Max Operating Temperature (F) | 120 |
| Max Particle Size (In) | 0.6000 |
| Viscosity | Vegetable Oil 34.60 cp 200.00 ssu |
| Mechanical Seal Face | SiC |
| Mechanical Seal Type | Single |
| Impeller Number (In.) | Q |
| Other | Applications: Chemical, waste water, marine, constructions, environmental, petroleum, emergency and plant clean-up. |
| Impeller Material | Urathane coated steel, Two blade non-clog |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | No |
| Run Time (HR.) | 3.4 |
| Fuel Tank Size | 1.3g |
| Country of Manufacture | United States |
| Weight (Lbs) | 133.000000 |
| Engine Brand | Hatz |
| Warranty (YRS.) | 1 |
>
