Submersible 3HP 3" Non-clog Pump
-
Model Number:
3BWSE302DS
-
Product Name:Submersible 3HP 3" Non-clog Pump
-
Manufacturer:
-
Series (49 Models):
200/230v/1 3HP Dbl Seal
Model Number
3BWSE302DS
40% Off
Special Price
$3,810.00
Regular Price
$6,350.00
Barmesa 3BWSE302DS
Submersible NON-CLOG sewage pump,
2" spherical solids handling, heavy duty.
Double Seal
25 ft. cord. All cast iron. Impeller Design: open, double vane. Material: cast iron ASTM A-48 class 30, dynamically balanced, ISO G6.3. Inboard, oil filled shaft seal
| Model Number | 3BWSE302DS |
|---|---|
| part number | 62170167 |
| Series | Barmesa Industrial Pumps |
| Max Flow (GPM.) | 350 |
| Max Flow GPH | 21000 |
| TDH Maximum (Ft) | 65 |
| TDH Maximum (PSI) | 28 |
| Horse Power (HP) | 3 |
| Horsepower (IE .5, 1, 1.5, 20) | 3 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 3 |
| Wetted Materials | Cast Iron |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 200/230 |
| Voltage (Range) | 208-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor Amps (A) | 28 |
| Motor | Hermetically Sealed |
| Speed (RPM.) | 1725 |
| Self Priming | No |
| Max Operating Temperature (F) | 104 |
| Max Particle Size (In) | 2.5 |
| Viscosity | Milk 3.20 cp 40.00 ssu |
| Shaft | 416SS |
| Mechanical Seal | oil filled |
| Mechanical Seal Face | SiC |
| Mechanical Seal Type | Double |
| Motor Bearings | Upper: Ball for radial, Lower: Ball for radial and thrust. Both are oil lubricated. |
| Impeller Size (IN.) | 7.0000 |
| Other | Single phase - thermal overload protected. |
| Impeller Material | CI Non-clog |
| Cord Size | 10-4 SJO |
| Cord Length (Ft.) | 40 |
| Duty | Continuous |
| Drain | No |
| Port Rotation | No |
| Country of Manufacture | Mexico |
| Weight (Lbs) | 225.000000 |
| Warranty (YRS.) | 1 |
| GPM Of Water At 30 Feet Of Head | 310 |
| GPM Of Water At 40 Feet Of Head | 250 |
| GPM Of Water At 50 Feet Of Head | 150 |
>
