Portable Fire Pumps 57HP
-
Model Number:
2-1/2AGE250DTZ
-
Product Name:Portable Fire Pumps 57HP
-
Manufacturer:
-
Series (12 Models):
Deutz Diesel
Model Number
2-1/2AGE250DTZ
$21,963.20
Darley 2-1/2AGE250DTZ
W.S. Darley & Co. has always been a leader in portable fire pump design. The High-Pressure Fire Pump is easy-starting, single stage, and reliable.
Features
- Engine: Deutz D914L03 Diesel: 57 HP, air-cooled, 12 volt, electric starter, alternator
- Engine control panel,Tachometer, Hour meter, Oil pressure gauge, Ammeter, Throttle, Muffler
- Start/stop key switch
- Inlet: 2.5" NPTF
- Outlet: 2.5" FNPT
- Aluminum alloy gear case and engine adapter, Bronze impeller and wear rings, Stainless steel impeller shaft
- 53.44"L x 27.88"W x 58.83"H, 700 lbs.
Performance:
- 115 gpm (435 L/M) @ 230 psi (15.8 bar)3
- 75 gpm (283 L/M) @ 285 psi (19.6 bar)
- 25 gpm (94 L/M) @ 295 psi (20.3 bar
Applications:
- Meets 250 gpm @ 150 psi for Type 2 Structure engines
- Meets 150 gpm @ 250 psi for Type 3 Wildland engines
Options include multiple discharge heads, 30g fuel tank, electric primer pumps.
Click here for the battery needed for electric start
| Model Number | 2-1/2AGE250DTZ |
|---|---|
| Series | Fire Pump High Volume |
| Max Flow (GPM.) | 300 |
| Max Flow GPH | 18000 |
| TDH Maximum (Ft) | 705 |
| TDH Maximum (PSI) | 305 |
| Horsepower (IE .5, 1, 1.5, 20) | 57 |
| Inlet Connection Type | FNPT |
| Inlet (In.) | 2.5 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 2.5 |
| Wetted Materials | Aluminum |
| Elastomers / O-ring | Buna-Nitrile |
| Motor | Diesel Engine |
| Speed (RPM.) | 3450 |
| Self Priming | No |
| Max Operating Temperature (F) | 140 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Coupling | N |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 700.000000 |
>
