Medium Head Work Horse Pump
-
Model Number:
MULP3005B3
-
Product Name:Medium Head Work Horse Pump
-
Manufacturer:
-
Series (11 Models):
5HP 230/460v
Model Number
MULP3005B3
$3,047.00
Munro MULP3005B3
Self-priming Work Horse. The impeller, diffuser, brackets, and
volutes are all made of cast iron. The suction flange includes a
flapper style check valve. Motor shaft is a full 1.25" diameter
(instead of the typical 56J at .625"). Motor is a NEMA JM standard
pump motor. Sturdy cast iron design engineered for years of trouble
free service. Made in USA.
| Model Number | MULP3005B3 |
|---|---|
| Series | Sprinkler Irrigation Pump LP |
| Max Flow (GPM.) | 222 |
| Max Flow GPH | 13320 |
| TDH Maximum (Ft) | 150 |
| TDH Maximum (PSI) | 65 |
| TDH BEP (FT.) | 100.000000 |
| Horse Power (HP) | 5 |
| Horsepower (IE .5, 1, 1.5, 20) | 5.0000 |
| Inlet Connection Type | FNPT |
| inlet size | 3" |
| Inlet (In.) | 3 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 3 |
| Wetted Materials | Cast Iron |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 230/460 |
| Voltage (Range) | 220-240/460-480 |
| Phase (Ø) | Three (3) |
| Motor Frequency | 60 |
| Motor | ODP |
| Speed (RPM.) | 3450 |
| Motor Frame | 182/4JM |
| Self Priming | Yes |
| Suction Lift (FT.) | 15 |
| Max Operating Temperature (F) | 140 |
| Viscosity | Milk 3.20 cp 40.00 ssu |
| Shaft | 304SS |
| Mechanical Seal | No |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Other | Order a motor controller / starter seperately for a complete package. |
| Impeller Material | Brass |
| Cord Length (Ft.) | 0 |
| Drain | Yes |
| Port Rotation | Yes |
| Country of Manufacture | United States |
| Weight (Lbs) | 144.000000 |
| Warranty (YRS.) | 1 |
>
