J Centrifugal Pump Med Head 1HP

230/460v
Model Number
JME3-58
$1,452.00
Sta-rite Centrifugal Pump High Pressure

Sta-Rite JME3-58

This pump has a heavy-duty cast iron construction with Noryl impeller.
  • Applications: Water systems and sprinkling for homes, farms and industry
  • Drain Port: Provided for easy winterizing
  • Easy Serviceability: Includes replaceable wear ring and feature back pull-out design
  • Rated for temperatures to 140ï½°F
  • Body and Seal Plate: Close-grained cast iron
  • Base: Steel 10 gauge
  • Shaft: 416 SS
More Information
Model Number JME3-58
Series J & JB Centrifugal Pump Starite
Max Flow (GPM.) 68
Max Flow GPH 4080
TDH Maximum (Ft) 85
TDH Maximum (PSI) 36
Horse Power (HP) 1
Horsepower (IE .5, 1, 1.5, 20) 1.0000
Inlet Connection Type FNPT
inlet size 1 ½"
Inlet (In.) 1.5
Outlet Connection Type FNPT
Outlet (In.) 1.25
Wetted Materials CI-Plastic
Elastomers / O-ring Buna-Nitrile
Voltage (V) 208-230/460
Voltage (Range) 208-240/460
Phase (Ø) Three (3)
Motor Frequency 60
Motor ODP
Speed (RPM.) 3450
Self Priming No
Max Operating Temperature (F) 140
Viscosity Water 1.00 cp 31.00 ssu
Shaft 416SS
Mechanical Seal Face Carbon-ceramic
Mechanical Seal Type Single
Other UL listed.
Impeller Material Noryl, closed
Cord Length (Ft.) 0
Drain Yes
Port Rotation Yes
Weight (Lbs) 47.000000
Warranty (YRS.) 1
