Inline Constant Pressure System (CP - 90411101)

Inline Constant Pressure System. Subdrive Water pump. Traditional municipal systems use city water lines to deliver water to your home. Depending on pipes and distance from the water main, pressure may not always be adequate. Traditional water well systems use a single-speed motor and pump to move water from the well to your home. However, when your demand for water increases, the pump speed stays the same. The Inline CP Constant Pressure System provides constant pressure for both private wells and municipal water systems. Boost the water pressure by up to 60psi. The Inline CP is versatile and can be used in place of the standard booster pump. In addition to its weatherproof NEMA 4 electronics enclosure, the Inline CP will adjust the overall system pressure, allowing complete water coverage and shorter system run times. The Inline CP provides a constant pressure solution for homes with low yielding wells, where storage tanks or cisterns are used. Applications

• Boosted and constant water pressure from water storage/cistern systems
• Homes - both in private and municipal applications
• General pressure boosting
• Sprinkler systems
• Farming and commercial wash down systems
• For homes on manucipal or private well systems
• For multi-family dwellings - duplexes,triplexes and quads
• For increased and consistant water pressure from water storage/cistern ststems
• For sprinkler and reclamation systems
• For general pressur boosting

Features

• A complete and packaged system (Pump, motor, drive and pressure sensor in one box)
• Small and compact design - Fits into small areas, even between floor joists
• Stainless steel construction - Made for years of operation
• Simple and easy installation - Step-by-step illustrated instructions
• Quiet and cool operation - Integrated motor design allows water to flow around it
• NEMA 4 (IP56) electronics enclosure
• Multiple mounting configurations - Install units where you need them: horizontal, vertical and even upside down
• Product power rating: 1.5 hp, 0.9 kW
• Shipping weight: 50 lbs, 22.7 kg
• Built in system protections guard the Inline unit from many common failure modes including: surge protection, voltage underload, locked pump, open circuit, short circuit and overheated controller.
