HTO 120 Pump END ONLY
-
Model Number:
29809
-
Product Name:HTO 120 Pump END ONLY
-
Manufacturer:
-
Series (5 Models):
5.96" imp.
Model Number
29809
$2,583.00
MP 29809
Centrifugal Hot Oil Pump END ONLY:
- Applications: Hot Oil, Heat Transfer Fluid, Asphalt plants, Plastics, Chemical, Food, and Processing Industries which require pumping of high temperature fluids. The HTO is used to move a heat transfer fluid on a double walled piping system.
- Utilizes an isolated seal chamber, effectively cooled by a fan clamp, which couples the unit to the shaft of a c-frame motor
- Standard carbon/ceramic mechanical seal with FKM elastomers, stainless steel fitted
- Carbon graphite isolator bushing separates mechanical seal from high temperature fluids
- Stainless steel drive sleeve and aluminum drive clamp couples pump unit to motor
- Vertical & Horizontal discharge
- A unique centrifugal pump (patented) designed for high temperature applications without requiring external flushes or jacket cooling
- Max working pressure: 150 PSI
- Uses a 184TC motor with a 7/8" shaft diameter
26586
Note impeller diameter allows for motor overload if run wide open. Discharge / flow restriction required. See curve or consult with PumpBiz application Engineer.
Model Number | 29809 |
---|---|
part number | MP29809 |
Series | HTO 120 Hot Liquid |
Max Flow (GPM.) | 198 |
Max Flow GPH | 11880 |
TDH Maximum (Ft) | 135 |
TDH Maximum (PSI) | 58 |
Horse Power (HP) | 5 |
HP Required | 5 |
Inlet Connection Type | FNPT |
Inlet (In.) | 2 |
Outlet Connection Type | FNPT |
Outlet (In.) | 1.5 |
Wetted Materials | Cast Iron |
Elastomers / O-ring | FKM |
Self Priming | No |
Max Operating Temperature (F) | 650 |
Viscosity | SAE 30 oil 352.00 cp 2000.00 ssu |
Mechanical Seal Face | Carbon-ceramic |
Mechanical Seal Type | Single |
Impeller Size (IN.) | 5.9600 |
Coupling | N |
Approvals | NEMA |
Impeller Material | CI |
Cord Length (Ft.) | 0 |
Drain | Yes |
Port Rotation | Yes |
Country of Manufacture | United States |
Weight (Lbs) | 65.000000 |
Warranty (YRS.) | 1 |
>
