High Pressure Centrifugal Pump

Model Number:

CT15B3
Product Name:

High Pressure Centrifugal Pump
Manufacturer:

Myers Pumps
Series (24 Models):

CT High Pressure Centrifugal Pumps

1.5HP 230/460v Brass impeller

Model Number

CT15B3

Specifications

$1,400.00

Email to a Friend Price Match

Skip to the end of the images gallery

Skip to the beginning of the images gallery

flow chart performance of CT pumps by myers

Myers CT15B3

1.5HP 3-phase Myers CT Series of centrifugal pumps are designed to meet your toughest pumping requirements. Rugged cast iron construction can be coupled with either a corrosion resistant composite, or a lead-free brass impeller. Versatile design features allow Crusader pumps to be installed with either a vertical or horizontal discharge. The CT Series is ideal for circulating, cooling towers, liquid transfer, sprinkling systems, general industrial service, irrigation, air conditioning, cooling tower and booster applications.

Double-Ball Bearing Motor
Continuous Duty Rated
Brass Impeller Rated to 212ï½°F
Maximum Working Pressure of 125 PSI
The compact, back pullout design provides easy installation and serviceability.
See the Miscellaneous Page for more information (click here)

More Information
Model Number	CT15B3
Series	CT High Pressure Centrifugal Pumps
Max Flow (GPM.)	62
Max Flow GPH	3720
TDH Maximum (Ft)	118
TDH Maximum (PSI)	51
Horse Power (HP)	1 1/2
Horsepower (IE .5, 1, 1.5, 20)	1.5000
Inlet Connection Type	FNPT
inlet size	1 ¼"
Inlet (In.)	1.25
Outlet Connection Type	FNPT
Outlet (In.)	1
Wetted Materials	Brass, Cast Iron
Elastomers / O-ring	FKM
Voltage (V)	208-230/460
Voltage (Range)	208-240/460
Phase (Ø)	Three (3)
Motor Frequency	60
Motor	ODP
Speed (RPM.)	3450
Motor Frame	56C
Self Priming	No
Max Operating Temperature (F)	212
Shaft	304SS
Mechanical Seal Face	Carbon-ceramic
Mechanical Seal Type	Single
Impeller Size (IN.)	5.312500
Approvals	CSA
Impeller Material	Brass, closed
Cord Length (Ft.)	0
Duty	Continuous
Drain	Yes
Port Rotation	Yes
Weight (Lbs)	42.000000
