High Pressure Bronze Centrifugal Pump
-
Model Number:
490B-97-1
-
Product Name:High Pressure Bronze Centrifugal Pump
-
Manufacturer:
-
Series (52 Models):
230/460v 3HP TEFC
Model Number
490B-97-1
$1,520.44
AMT 490B-97-1
High Head Centrifugal Pumps. Designed for continuous duty, high
pressure, high flow, general service water circulation and transfer
(boosting water in high rise apartments, hotels & office
buildings, circulation of hot & chilled water, pressure
boosting for cooling towers). Series 49 is 1.50" & 1.25. These
pumps are made in USA, unlike other clones made in China and
India.
See Curve "E"
Include Silicon Carbide / Buna N Type 31 Seal Factory installed: 490X-300-VS
For 316SS version of same pump see 490B-98
Series: Centrifugal High Pressure Pumps
| Model Number | 490B-97-1 |
|---|---|
| part number | 490B-999-97 |
| Series | Centrifugal High Pressure Pumps 34-64 psi |
| Max Flow (GPM.) | 108 |
| Max Flow GPH | 6480 |
| TDH Maximum (Ft) | 130 |
| TDH Maximum (PSI) | 62 |
| Horse Power (HP) | 3 |
| Horsepower (IE .5, 1, 1.5, 20) | 3.0000 |
| inlet size | 1 ½" |
| Inlet (In.) | 1.5 |
| Outlet (In.) | 1.25 |
| Wetted Materials | 316SS, Bronze |
| Voltage (V) | 230/460 |
| Voltage (Range) | 220-240/460-480 |
| Motor | TEFC |
| Speed (RPM.) | 3450 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Length (In.) | 16.000000 |
| Motor Bearings | Ball |
| Other | amt pump |
| Impeller Material | Stainless Steel, Closed |
| Cord Length (Ft.) | 0 |
| Port Rotation | Yes |
| Weight (Lbs) | 50.000000 |
| UPC | 072684650805 |
| Warranty (YRS.) | 1 |
>
