High Pressure Bronze Centrifugal Pump
-
Model Number:
4902-97
-
Product Name:High Pressure Bronze Centrifugal Pump
-
Manufacturer:
-
Series (52 Models):
115/230v 1-1/2HP ODP
Model Number
4902-97
$1,517.25
AMT 4902-97
High Head Centrifugal Pumps. Designed for continuous duty, high
pressure, high flow, general service water circulation and transfer
(boosting water in high rise apartments, hotels & office
buildings, circulation of hot & chilled water, pressure
boosting for cooling towers). Series 48 inlet & outlet are
1.25" & 1" while series 49 is 1.50" & 1.25
respectively.
See Curve "D"
Include Silicon Carbide / FKM N Type 31 Seal Factory installed: 489X-300-VS
Series: Centrifugal High Pressure Pumps
| Model Number | 4902-97 |
|---|---|
| part number | 4902-999-97 |
| Series | Centrifugal High Pressure Pumps 34-64 psi |
| Max Flow (GPM.) | 95 |
| Max Flow GPH | 5700 |
| TDH Maximum (Ft) | 80 |
| TDH Maximum (PSI) | 35 |
| Horse Power (HP) | 1 1/2 |
| Horsepower (IE .5, 1, 1.5, 20) | 1.5000 |
| inlet size | 1 ½" |
| Inlet (In.) | 1.5 |
| Outlet (In.) | 1 |
| Wetted Materials | 316SS, Bronze |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 115/230 |
| Voltage (Range) | 110-120/220-240 |
| Motor Amps (A) | 2 |
| Motor | ODP |
| Motor Frame | 56J thrd |
| Self Priming | ---- |
| Suction Lift (FT.) | 5 |
| Max Operating Temperature (F) | 120 |
| Max Particle Size (In) | .2 |
| Viscosity | Milk 3.20 cp 40.00 ssu |
| Length (In.) | 15.500000 |
| Mechanical Seal Face | SiC |
| Mechanical Seal Type | Single |
| Motor Bearings | Ball |
| Impeller Size (IN.) | b |
| Impeller Number (In.) | 3 |
| Other | amt pump |
| Rotation | cw |
| Cord Length (Ft.) | 0 |
| Duty | Continuous |
| Drain | No |
| Country of Manufacture | United States |
| Weight (Lbs) | 50.000000 |
| UPC | 072684650131 |
| Warranty (YRS.) | 1 |
| GPM Of Water At 50 Feet Of Head | 70 |
| GPM Of Water At 90 Feet Of Head | 30 |
