High Pressure Bronze Centrifugal Pump
-
Model Number:
4901-97
-
Product Name:High Pressure Bronze Centrifugal Pump
-
Manufacturer:
-
Series (52 Models):
3HP 230/460v ODP
Model Number
4901-97
25% Off
Special Price
$1,112.44
Regular Price
$1,483.25
AMT 4901-97
High Pressure Centrifugal Pump Series Page Link. Bronze High
Head Centrifugal Pumps. Designed for continuous duty, high
pressure, high flow, general service water circulation and transfer
(boosting water in high rise apartments, hotels & office
buildings, circulation of hot & chilled water, pressure
boosting for cooling towers). Series 48 inlet & outlet are
1.25" & 1" while series 49 is 1.50" & 1.25
respectively.
See Curve "F"
| Model Number | 4901-97 |
|---|---|
| part number | 4901-999-97 |
| Series | Centrifugal High Pressure Pumps 34-64 psi |
| Max Flow (GPM.) | 120 |
| Max Flow GPH | 7200 |
| TDH Maximum (Ft) | 148 |
| TDH Maximum (PSI) | 64 |
| Horse Power (HP) | 3 |
| Horsepower (IE .5, 1, 1.5, 20) | 3.0000 |
| Inlet Connection Type | FNPT |
| inlet size | 1 ½" |
| Inlet (In.) | 1.5 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1.25 |
| Wetted Materials | 316SS, Bronze |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 208-230/460 |
| Voltage (Range) | 208-240/460 |
| Motor | ODP |
| Self Priming | ---- |
| Suction Lift (FT.) | 5 |
| Max Operating Temperature (F) | 120 |
| Max Particle Size (In) | .125 |
| Viscosity | Glycerine 880.00 cp 5000.00 ssu |
| Length (In.) | 15.200000 |
| Mechanical Seal Face | Carbon-ceramic |
| Motor Bearings | Ball |
| Impeller Size (IN.) | a |
| Impeller Number (In.) | 1 |
| Other | amt pump |
| Rotation | cw |
| Impeller Material | Stainless Steel, Closed |
| Cord Length (Ft.) | 0 |
| Duty | Continuous |
| Port Rotation | Yes |
| Country of Manufacture | United States |
| Weight (Lbs) | 50.000000 |
| UPC | 072684650136 |
