Centrifugal Pump High Head 3/4HP
-
Model Number:
JHD3T
-
Product Name:Centrifugal Pump High Head 3/4HP
-
Manufacturer:
-
Series (46 Models):
TEFC 230/460v
Model Number
JHD3T
Sta-Rite JHD3T
This pump has a heavy-duty cast iron construction with Noryl
impeller.
- Applications: Car Wash, Water systems and sprinkling for homes, farms and industry
- Drain Port: Provided for easy winterizing
- Easy Serviceability: Includes replaceable wear ring and feature back pull-out design
- Rated for temperatures to 140ï½°F
- Body and Seal Plate: Close-grained cast iron
- Base: Steel 10 gauge
- Shaft: 416 SS
| Model Number | JHD3T |
|---|---|
| Series | J & JB Centrifugal Pump Starite |
| Max Flow (GPM.) | 47 |
| Max Flow GPH | 2820 |
| TDH Maximum (Ft) | 100 |
| TDH Maximum (PSI) | 43 |
| Horse Power (HP) | 3/4 |
| Horsepower (IE .5, 1, 1.5, 20) | 0.7500 |
| Inlet Connection Type | FNPT |
| inlet size | 1 ¼" |
| Inlet (In.) | 1.25 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1 |
| Wetted Materials | CI-Plastic |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 208-230/460 |
| Voltage (Range) | 208-240/460 |
| Phase (Ø) | Three (3) |
| Motor Frequency | 60 |
| Self Priming | No |
| Max Operating Temperature (F) | 140 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Shaft | 416SS |
| Motor Bearings | Ball |
| Rotation | CW from motor side |
| Impeller Material | Lexan, enclosed |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | Yes |
| Country of Manufacture | United States |
| Weight (Lbs) | 44.000000 |
| Warranty (YRS.) | 1 |
