Booster Pump
-
Model Number:
HPS20F-01
-
Product Name:Booster Pump
-
Manufacturer:
-
Series (37 Models):
1-1/2HP 1" 115/230v Stainless
Model Number
HPS20F-01
$3,251.00
Sta-Rite HPS20F-01
Stainless Steel Booster Pump is the most durable booster pump available. The
patented SignaSeal™ floating impeller design minimizes
thrust loads allowing for continuous operation without damage to
motor bearings, mechanical seal or pump hydraulic components.
HP signifies Cast Iron Pump Body. HPS signifies SS
Pump Inlet and Discharge casting. All pumps have a 304SS pump
shell.
- Applications:
- Car wash
- Filtration and reverse osmosis
- Residential, commercial or agricultural pressure washing
- Booster and spray systems
- HVAC
- General purpose pumping
- Max. Inlet Pressure: 80 PSI
- Max. Working Pressure: 315 PSI
- Diffuser: Polycarbonate
- Heavy-Duty ball bearings: shielded, permanently lubricated bearings.
- Dustproof Cover: all electrical components are protected from dirt, dust and insects by a dustproof canopy; ventilating air cannot contaminate
| Model Number | HPS20F-01 |
|---|---|
| Series | HP HPS High Pressure Booster Pump |
| Max Flow (GPM.) | 20 |
| Max Flow GPH | 1200 |
| TDH Maximum (Ft) | 345 |
| TDH Maximum (PSI) | 149 |
| Horse Power (HP) | 1 1/2 |
| Horsepower (IE .5, 1, 1.5, 20) | 1.5000 |
| Inlet Connection Type | FNPT |
| inlet size | 1" |
| Inlet (In.) | 1 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 1 |
| Wetted Materials | 304SS, Acetal-Delrin |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 115/230 |
| Voltage (Range) | 110-120/220-240 |
| Phase (Ø) | Single (1) |
| Motor Frequency | 60 |
| Motor | ODP |
| Speed (RPM.) | 3450 |
| Self Priming | No |
| Suction Lift (FT.) | 15 |
| Max Operating Temperature (F) | 140 |
| Viscosity | Water 1.00 cp 31.00 ssu |
| Stages | 9 |
| Shaft | 304SS |
| Length (In.) | 29.830000 |
| Mechanical Seal Face | Carbon-ceramic |
| Mechanical Seal Type | Single |
| Impeller Material | Plastic, closed |
| Cord Size | 0 |
| Drain | No |
| Port Rotation | No |
| Weight (Lbs) | 65.000000 |
| Warranty (YRS.) | 1 |
