Big Twin Piston Pump Hollow Shaft
-
Model Number:
5206C-H
-
Product Name:Big Twin Piston Pump Hollow Shaft
-
Manufacturer:
-
Series (4 Models):
Model Number
5206C-H
$3,052.18
Hypro 5206C-H
Hypro Corporation's Twin piston pumps are used in a variety of
spraying and pressure cleaning applications, as well as hydrostatic
testing. These heavy-duty pumps are ideal for fluid handling of
water and nonabrasive or general use chemicals. All pumps are
constructed from cast iron materials. They feature SS valves and
ball bearing, leather or fabric-reinforced Buna-N or straight
Buna-N cups. You can choose from a variety of drive systems to
include: belt and pulley, 540 rpm PTO, gasoline engine or electric
motor.
- Nonabrasive and general use chemical compatibility
- Compact, lightweight and easy to install
- Replaceable leather cups for insecticides, herbicides and aromatic solvents
- Replaceable Buna-N and fabric reinforced Buna-N cups for water, soap and detergent solutions
- They are bi-rotational
- Self priming operation
- Fluid temperatures up to 140ï½°F
- Max rated RPM: 800
- Leather cups and Ni-Resist sleeves
- 1" hollow shaft with base
- Click here to view accessories for this pump
| Model Number | 5206C-H |
|---|---|
| Series | Piston Pumps 5200 Big Twin 10gpm |
| Max Flow (GPM.) | 8 |
| Max Flow GPH | 480 |
| TDH Maximum (Ft) | 924 |
| TDH Maximum (PSI) | 400 |
| Inlet Connection Type | FNPT |
| inlet size | Less than 1in |
| Inlet (In.) | 0.75 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 0.75 |
| Wetted Materials | Cast Iron, Ni-Resist |
| Self Priming | Yes |
| Max Operating Temperature (F) | 140 |
| Mechanical Seal | No |
| Mechanical Seal Type | Double |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 18.000000 |
>
