6" Diesel Trash Pump
-
Model Number:
TP-150/DZ/T
-
Product Name:6" Diesel Trash Pump
-
Manufacturer:
PumpBiz 36HP
Model Number
TP-150/DZ/T
$30,323.70
PumpBiz TP-150/DZ/T
6" Diesel Trash Pump is designed for applications requiring high volume flow and solid debris handling capabilities. Diesel engine Deutz 3FL2011. Pump is constructed of heavy duty class 30 Cast-iron with volute for wear resistance and durability. For use with non-flammable liquids which are compatible with pump component materials.
- Two-vane, dynamically balanced, non-clogging open impeller, ductile iron construction with rear equalizer vanes to reduce axial loading, and increase mechanical seal life.
- Tungsten Carbide hardened seal faces for periods of short, dry running
- Stainless Steel Impeller
- Discharge Check Valve Weighted, full flow inlet to eliminate priming during start-up cycle
- 6" NPT Port Size
- Self Priming to 28 Ft.
- Diesel engine Deutz
- Diesel engine with 26hrs run time diesel tank
- Solids Handling to 2-7.8x2in Diameter
-
WARNING: Use only with nonflammable liquids compatible
with pump component materials and in nonflammable/nonexplosive
atmospheres.
Series: Gas Diesel Engine Trash Pumps
| Model Number | TP-150/DZ/T |
|---|---|
| Max Flow (GPM.) | 1200 |
| Max Flow GPH | 72000 |
| TDH Maximum (Ft) | 140 |
| Horsepower (IE .5, 1, 1.5, 20) | 36.0000 |
| Inlet Connection Type | MNPT |
| inlet size | 6" |
| Inlet (In.) | 6 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 6 |
| Wetted Materials | 304SS, Aluminum, Cast Iron |
| Elastomers / O-ring | Buna-Nitrile |
| Motor | Diesel Engine |
| Speed (RPM.) | variable |
| Self Priming | Yes |
| Suction Lift (FT.) | 28 |
| Max Operating Temperature (F) | 212 |
| Viscosity | Cream 16.50 cp 100.00 ssu |
| Mechanical Seal | TYPE 21 |
| Mechanical Seal Face | SiC |
| Mechanical Seal Type | Single |
| Other | 3 cylinder, air cooled engine, naturally aspired, direct injection |
| Low Oil Shutdown | Yes |
| Impeller Material | Two vane open impeller, ductile iron |
| Duty | Continuous |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 1875.000000 |
| Warranty (YRS.) | 1 |
>
