316SS Pump 10HP PEO
-
Model Number:
BCSF2x3-538
-
Product Name:316SS Pump 10HP PEO
-
Manufacturer:
-
Series (5 Models):
10hp PEO
Model Number
BCSF2x3-538
$3,799.00
Barmesa BCSF2x3-538
316SS End Suction centrifugal Pump End Only PEO is designed for continuous duty high pressure OEM, industrial / commercial and general service applications including circulation, chemical processing, liquid transfer, cooling, sprinkler / fire protection systems & pressure boosting. Cast AISI 316 Stainless Steel.
Features:
- Pump Kit for electric motors. 213-215JM 3450 10HP
- Carbon / Silicon-Carbide / FKM shaft seal
- Open impeller handles up to 3/8" solids
- Max. Temp 250F
- Max. Working Pressure 175 PSIG
- Drain plug
- Four position discharge orientation.
Replaces ICS
| Model Number | BCSF2x3-538 |
|---|---|
| part number | 31076713 |
| Series | BCS End-Suction Centrifugal Pumps |
| Max Flow (GPM.) | 375 |
| Max Flow GPH | 22500 |
| TDH Maximum (Ft) | 120 |
| TDH Maximum (PSI) | 52 |
| HP Required | 10 |
| Inlet Connection Type | Flange |
| Inlet (In.) | 3 |
| Outlet Connection Type | Flange |
| Outlet (In.) | 2 |
| Wetted Materials | 316SS |
| Elastomers / O-ring | FKM |
| Speed (RPM.) | 3600 |
| Motor Frame | 215JM |
| Self Priming | No |
| Max Operating Temperature (F) | 250 |
| Max Particle Size (In) | 0.1 |
| Viscosity | Cream 16.50 cp 100.00 ssu |
| Shaft | 316SS |
| Mechanical Seal Face | Silicon Carbide |
| Impeller Size (IN.) | 5.38 |
| Impeller Material | 316 SS, Closed |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 79.000000 |
| Warranty (YRS.) | 1 |
>
Barmesa Pumps LLC started operations in 1953, manufacturing small self-primer pumps, jet pumps and end suction centrifugal pumps for the rural market.
During the 1970's, new additions were made to the line of products and we started manufacturing submersible solids handling pumps as well as grinder pumps.
Today after more than 60 years, we have manufacturing facilities & distribution centers across America, and an extensive distributor network. Our State of the Art manufacturing facilities have modern CNC machinery as well sophisticated design and test capabilities. Barmesa serves markets such as marine, commercial, municipal, wastewater, water, industrial, construction, utility, chemical, OEM, irrigation, dewatering flood control, fire protection, as well as many other applications.
Our privately held family business is committed to offer an extensive variety of products with the best quality standards and on-time deliveries. We are proud to say "Quality Pumps Since 1953".
During the 1970's, new additions were made to the line of products and we started manufacturing submersible solids handling pumps as well as grinder pumps.
Today after more than 60 years, we have manufacturing facilities & distribution centers across America, and an extensive distributor network. Our State of the Art manufacturing facilities have modern CNC machinery as well sophisticated design and test capabilities. Barmesa serves markets such as marine, commercial, municipal, wastewater, water, industrial, construction, utility, chemical, OEM, irrigation, dewatering flood control, fire protection, as well as many other applications.
Our privately held family business is committed to offer an extensive variety of products with the best quality standards and on-time deliveries. We are proud to say "Quality Pumps Since 1953".
