12VDC diesel fuel pump
-
Model Number:
FR1210G
-
Product Name:12VDC diesel fuel pump
-
Manufacturer:
-
Series (10 Models):
Model Number
FR1210G
$413.00
Sotera FR1210G
This industry standard DC pump dispenses up to 15 GPM (57 LPM). The
FR1210G is ideal for pumping gas, diesel fuel and kerosene. With an
amp draw that's easy on your DC power source. Explosion-proof
UL/cUL listed 1/4 HP motor. The FR1210G comes complete with 12 ft.
static wire hose and manual nozzle..click
here to view the digital meter page.
Features:
2 year warranty
2 in. threaded base for tank mounting
Cast bronze rotor with bronze rotary vanes
15 gpm
12VDC
On/Off switch
Built-in strainer.
12 ft. hose with static wire.
SS460| Model Number | FR1210G |
|---|---|
| Series | Electric Transfer Pump |
| Max Flow (GPM.) | 15 |
| Max Flow GPH | 900 |
| TDH Maximum (Ft) | 19 |
| TDH Maximum (PSI) | 15 |
| Horse Power (HP) | 1/4 |
| Horsepower (IE .5, 1, 1.5, 20) | 0.2500 |
| Inlet Connection Type | FNPT |
| Inlet (In.) | 1 |
| Outlet Connection Type | FNPT |
| Outlet (In.) | 0.75 |
| Wetted Materials | Cast Iron |
| Elastomers / O-ring | Buna-Nitrile |
| Voltage (V) | 12DC |
| Voltage (Range) | 12/24/36 VDC |
| Motor | EXP (C 1, Gp D) |
| Self Priming | Yes |
| Viscosity | Catsup 3000.00 cp 20000.00 ssu |
| Mechanical Seal | No |
| Other | UL, cUL Motor, ATEX, CE**, ANZEx. Duty cycle 30 min. |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 32.000000 |
| Warranty (YRS.) | 2 |
>
