1" Bottom Discharge Flap Valve
-
Model Number:
FP04FEEA0A1J0
-
Product Name:1" Bottom Discharge Flap Valve
-
Manufacturer:
Model Number
FP04FEEA0A1J0
$735.00
Myers FP04FEEA0A1J0
Myers Flap Valve pumps are especially recommended for liquids which are
viscous or solid-laden. Flap valves allow passage of larger
suspended solids than most ball valve units without damage. These
pumps are ATEX compliant.-aluminum check valves-EPDM Diaphragm
| Model Number | FP04FEEA0A1J0 |
|---|---|
| Max Flow (GPM.) | 42 |
| Max Flow GPH | 2520 |
| TDH Maximum (Ft) | 288 |
| TDH Maximum (PSI) | 125 |
| Outlet (In.) | 1 |
| Wetted Materials | Aluminum |
| Elastomers / O-ring | EPDM |
| Diaphragm | EPDM |
| Self Priming | Yes |
| Suction Lift (FT.) | 25 |
| Viscosity | SAE 30 oil 352.00 cp 2000.00 ssu |
| Mechanical Seal | No |
| Mechanical Seal Type | Double |
| Other | Pump will dry prime to 10FT, for longer suction lengths fill pump chamber with liquid first. |
| Drain | Yes |
| Port Rotation | Yes |
| Weight (Lbs) | 31.000000 |
| Warranty (YRS.) | 1 |
>
