1" Bottom Discharge Flap Valve-cloned

  • Model Number:

    FP04FEES0A1J0

  • Product Name:
    1" Bottom Discharge Flap Valve-cloned
  • Manufacturer:
    PumpBiz
Model Number
FP04FEES0A1J0
Specifications
$1,583.00
Email to a Friend Price Match
Add to Wish List Add to Compare
Email
1" Bottom Discharge Flap Valve-cloned
1" Bottom Discharge Flap Valve-cloned 1" Bottom Discharge Flap Valve-cloned

PumpBiz FP04FEES0A1J0

Flap Valve pumps are especially recommended for liquids witch are viscous or solid-laden. Flap valves allow passage of larger suspended solids than most ball valve units without damage. These pumps are ATEX compliant -WR-S Check valve-EPDM diaphragm
More Information
Model Number FP04FEES0A1J0
Max Flow (GPM.) 42
Max Flow GPH 2520
TDH Maximum (Ft) 288
TDH Maximum (PSI) 125
Outlet (In.) 1
Wetted Materials 316SS
Elastomers / O-ring EPDM
Self Priming Yes
Mechanical Seal No
Mechanical Seal Type Double
Drain Yes
Port Rotation Yes
Weight (Lbs) 48.000000
>
