Product Name:

Fiberwound FRP Pressure tank 20gal

Model Number:



Sta-Rite Signature 2000 Fiberglass FRP pressure tank for water systems. Use wherever pressurized tanks are needed in water systems applications. 5 year warranty.
  • Durable Composite Construction: A rugged one-piece molded, inner-liner of premium high-density polyethylene.
    • Miles of continuous overlapping fiberglass strands, sealed with oven cured epoxy make the outer-shell impervious to rust, dents, and ultra-violet rays
    • Proprietary wrap pattern makes the tank stronger than steel. Tanks can be installed with a wider range of pressure settings, so you can select the system pressure you want.
  • Air Cell: The air cell is fabricated from durable and extensively tested ethyl-vinyl-acetate (EVA). Classified to ANSI/NSF Standard 61 for water system components.
    • EVA is resistant to chlorine, will not support iron bacteria growth that may be present in the water supply, and Polyethylene meet FDA requirements for potable water supplies
  • Tank Base: Rigid molded polyethylene. Corrosion and impact-resistant. Base rotates 360ï½° for ease-of-service hook-up.
  • Replaceable Air Cell: With the tank installed! Air cell access is via a top mount design. Generous and accessible air cell opening facilitates easy removable and re-installation of replacement air cell.
  • Specifications
    • Outer Shell: Fiberglass-wound and epoxy resin sealed
    • Upper and Lower Flanges: Reinforced polypropylene
    • Air Valve: Brass body, Schrader core assembly
    • Weather Cap: High density polyethylene
  • 20 Gallons
  • Diameter: 16"
  • Height: 36"

Additional Information

Model Number PSC-20-6-01
Self Priming Yes
Drain Yes
Port Rotation Yes
Country of Manufacture
Weight (Lbs) 27
Time to Ship (DAYS) 1 day
